Wireless Water Level Controller
Features :
- Wireless water level sensing and control
- Microcontroller-based intelligent operation
- Supports float switch, carbon & S.S. sensors
- Suitable for overhead and underground tanks
- Auto / Manual mode
- Automatic pump cut-off when tank is full
- Tank level LED indication
- Adjustable overload and dry-run protection
- Wall-mount installation
- Heavy-duty ABS enclosure
Technical Details :
The Wireless Water Level Controller offers remote, wireless monitoring and automatic pump management for overhead and underground water tanks. Its intelligent controller supports multiple sensor types and provides adjustable overload and dry-run protection.
Models
| Model No. |
|---|
| LLC RFM |
| LLC RFS |
Input
| Input Type |
|---|
| Universal Sensor Support – Float Switch, Carbon & S.S. |
Output
| Output Type |
|---|
| 230 VAC, 30A Relay |
| Suitable up to 2.0 HP Motor |
Specifications
| Specification | Details |
|---|---|
| Input Supply | 230 VAC, ±10%, 50 Hz |
| Output | 230 VAC, 30A Relay |
| With Obstacle Range | 15 MTR, Vertical |
| Without Obstacle Range | 50 MTR, Vertical |
| Enclosure Material | Industrial Grade Natural ABS |
| Overload Range | 0.5 to 20 AMP, Settable |
| Dry Run Range | 0.5 to 19 AMP, Settable |
