3 Phase Current Controller
Features :
- Three-phase current monitoring
- Three-line digital display
- Under-current and over-current monitoring
- Current unbalance detection
- Phase-loss detection
- 0.56" red LED display
- Compact 96 × 96 mm panel design
- Polycarbonate and ABS plastic enclosure
Technical Details :
The 3 Phase Current Controller is a digital monitoring device designed to measure and supervise current across three-phase electrical systems. It provides a clear three-line display with current unbalance and phase-loss monitoring, making it suitable for reliable current measurement and protection applications.
Models
| Parameter | Details |
|---|---|
| Model | CC 9633 |
| Frame | 96 × 96 |
| Panel | 92 × 92 |
| Display | 3 + 3 + 3 Digit, 0.56" Red |
Input
| Parameter | Details |
|---|---|
| Input Type | AC Current |
| Input Range | 0–5 AMP AC Direct or up to 2000 / 5 CT Selection |
| Setting | Factory Set |
Specifications
| Parameter | Details |
|---|---|
| Supply Voltage | 230 VAC, ±10%, 50Hz |
| Current Range | 0–2000 AMP AC or 0–2500 AMP DC |
| Accuracy | ±1% of FSD |
| Enclosure Material | Polycarbonate + ABS Plastic |
| Operating Temperature | 0°C – 55°C |
| Relative Humidity | Up to 95% RH, Non-Condensing |
| Available Direct Inputs | 30A AC / 50A AC / 100A AC / 200A AC |
No input details available.
No output details available.
No specifications details available.
