LLC 35 Water Level Controller
Features :
- High and low water level LED indication
- Automatic pump control
- Dry-run protection
- Overflow protection
- Adjustable 0–10 second delay
- Relay-based pump switching
- Suitable for drain and fill applications
- Compact panel-mount design
Technical Details :
The LLC 35 Water Level Controller is a compact automatic level monitoring solution for controlling pumps in lower and upper tanks. It provides clear level indication and helps protect the pump against dry-run and overflow conditions.
Models
| Model |
|---|
| LLC 35 |
Input
| Input Type |
|---|
| SS Type / Float Sensor |
Output
| Output Type |
|---|
| 1 Relay, 1 C/O, 5A |
Specifications
| Specification | Details |
|---|---|
| Supply Voltage | 230 VAC |
| Frequency | 50 Hz |
| Relay Output | 1 Relay, 1 C/O, 5A |
| Delay Time | 0–10 Seconds |
| Size (H × W × D) | 75 × 35 × 105 mm |
No input details available.
No output details available.
No specifications details available.
